Scotch Yoke Actuator
High-torque scotch yoke actuator for large ball valves and butterfly valves. Optimized torque profile for valve breakaway. Heavy-duty construction.
About Scotch Yoke Actuator
High-torque scotch yoke actuator for large ball valves and butterfly valves. Optimized torque profile for valve breakaway. Heavy-duty construction.
Technical Specifications
| Size Range | Torque 500 Nm - 10,000 Nm |
| Pressure Class | 4-8 bar |
| Design Standard | ISO 5211, ATEX / IECEx |
| Body Materials | Carbon Steel, Stainless Steel 316 |
| Parent Standards | ISO 5211, NAMUR, ATEX / IECEx |
| Parent Size Range | Torque 10 Nm - 10,000 Nm |
| Parent Pressure Class | Supply Pressure 4-8 bar |
Product Downloads
Product catalogs will be available soon.
Request documentation →Other Pneumatic Actuators Series
Rack & Pinion Actuator
Compact rack-and-pinion design for ball valve, butterfly valve and plug valve automation. Double-acting or spring-return. NAMUR accessory mounting.
Pneumatic Cylinder
Linear pneumatic cylinder for gate valve, globe valve and knife gate valve actuation. Double-acting design with adjustable cushioning. Clevis or trunnion mounting.
| Size Range | Torque 500 Nm - 10,000 Nm |
| Pressure Class | 4-8 bar |
| Design Standard | ISO 5211, ATEX / IECEx |
| Body Materials | Carbon Steel, Stainless Steel 316 |
